Werma 783EX Rotating Mirror

The Werma 783Ex Rotating Mirror is suitable for Zone 1, 2, 21 and 22.

Add to quote

The Werma 783Ex Rotating Mirror is suitable for Zone 1, 2, 21 and 22. The Werma 783Ex has a flame-proof enclosure and is saltwater-proof. It has a high life duration thanks to the low wear wheel and disc drive.

Interface

Screwable connection max. 2.5 mm2 single wire
Rotation rate

180 1/min
Color

Red
Cable entry

Cable diameter 5 – 13 mm

,

Cable gland M20 x 1.5
Life duration

Min. 5,000 h (bulb: dependent on illuminant)
Dimensions

195 x 305 mm
Ingress protection

IP66
Voltage

115V
Voltage type

AC/DC
Current consumption

350 mA
Housing

Aluminium, salt-water proof
Dome material

Borosilicate glass
Protection ignition

Ex II 2G Ex de IIC T3
Type of signal

Rotating Mirror
Lamp

Halogen G 6.35 35 W 12V/24V
Approvals

PTB 06 ATEX 1039
SKU: Werma-783EX Categories: , , Tag:
